Z-Type Bucket Elevator-Henan Keming Machinery Equipment Co., Ltd.

Parameter

Model	YDZD-2L	YDZD-3L	YDZD-5L	YDZD-7L	YDZD-10L
conveying capacity （m³/h）	0-6	0-0.75	0-12	0-15	0-20
running speed （m/min）	9-11	9-11	9-11	9-11	9-11
Single bucket capacity	2L	3L	5L	7L	10L
increase height	Customize	Customize	Customize	Customize	Customize
Material of hopper	Customize	Customize	Customize	Customize	Customize

Advantages

Casing

The casing provides effective sealing, which helps limit environmental contamination. The casing material can be selected according to production requirements, and stainless steel options are available.

Buckets

Depending on application needs, the buckets can be manufactured from ABS, stainless steel, or carbon steel to accommodate the conveying of high-temperature or corrosive materials.

Inlet and outlet ports

Single or multiple inlet/outlet ports can be customized to suit downstream single‑point or multi‑point feeding requirements. A constant‑speed feeding system can be incorporated to support uniform material supply.

Compact footprint

The Z‑type elevator features a compact footprint, owing to its flexible modular configuration, compact body, and horizontal‑vertical‑horizontal conveying path, which reduces the overall floor space required.

Model style

With the continuous progress of technology and the expansion of application,fields, Various models and speclicattios hase a be gtrdvelty devlelopon thzpusiet toagnuallat industreir t fieirts, variious models and spediction environment, hs e ZC.C Cype, F types andiand d erven ladder type with hover than 90° curtiing.For specific solutions, pserase soilutions, pleasrelnt Xinkiang Kellia Machineryfor free free design drawings.

Applicable Material

Granular Materials

Cereals, rice, corn, peanuts, nuts, candies, puffed pellets, pet feed, plastic pellets, fertilizer granules, pills, silica gel desiccants, seeds, resin pellets, etc.

Powder Materials

Flour, starch, powdered sugar, medicinal powder, activated carbon, talcum powder, calcium carbonate, feed premix powder, graphite powder, various dry powder additives, etc.

Flaky & Small Lump Materials

Tea leaves, dried fruits, oatmeal, herbal slices, tablets, small plastic parts, fine quartz sand, refractory small aggregates, etc.

Applicable Industries

Food & Grain Processing

Core Advantages: Food-grade stainless steel or PP buckets are optional; fully enclosed structure avoids external contamination. The material breakage rate can be controlled below 0.5%, making it ideal for fragile puffed food and nuts.

Chemical & Pharmaceutical Industry

Core Advantages: Fully sealed unit with zero leakage and dust emission. Buckets can be customized with corrosion-resistant materials such as SUS316L stainless steel; explosion-proof design is available for special working conditions.

Feed & Fertilizer Industry

Core Advantages: Large conveying capacity up to 100 cubic meters per hour; supports multi-point discharge to supply materials to multiple silos in one production line.

Building Materials & Metallurgy Industry

Core Advantages: Cost-effective and durable carbon steel construction; fully enclosed casing reduces dust pollution in workshops.

Applicable Industries

Not recommended for the following materials

Sticky materials

These tend to adhere to the bucket and casing surfaces, which can lead to blockages and impede smooth conveying.

Fine powders with high moisture content

SSuch materials are prone to agglomeration, which may affect flowability and reduce conveying efficiency.

Large or sharp materials

These could potentially cause damage to the equipment or result in jamming.

Frequently Asked Questions

Q1:What materials can the Z type bucket elevator handle?

It is suitable for granular materials, powders, food products, chemicals, plastics, grains and other bulk materials.

Q2: Can the equipment achieve multi-point feeding and discharging?

Absolutely. Both the inlet and discharge points of the Z-Type Elevator can be customized according to customer needs. Through special automatic discharge devices, multiple discharge points can be set on the top horizontal section, making it perfect for distributing materials to multiple silos or combination scales.

Q3: When conveying materials with high powder content, will there be dust emission?

No. The Z-Type Bucket Elevator features a fully enclosed casing with excellent sealing performance. Additionally, we recommend using a constant-speed vibratory feeder at the inlet for flow-in feeding, which fundamentally prevents dust emission and material spillage, ensuring a clean workshop environment.
